Creality Ender 3 V3 – Reliable FDM 3D Printer in Egypt

The Ender 3 V3 from Creality brings new impetus to the high-speed 3D printer market. Not only does its breathtaking speed of up to 600 mm/s and a maximum acceleration of 20,000 mm/s² make the Bed Slinger an outstanding design, but it also attracts everyone's attention when it comes to innovations. With a clog-free extruder kit including a “Unicorn” quick-swap nozzle, sophisticated part cooling and a robust yet elegant design, this 3D printer stands out from the standard.

Features at a glance:

• CoreXZ structure,
• Build volume of 220 x 220 x 250 mm,
• Stable, die-cast aluminium alloy frame,
• Max. printing speed of 600 mm/s,
• Max. acceleration of 20,000 mm/s²,
• Precise Z-axis linear guide and a fully automatic timing belt,
• Direct drive extruder with a bolster spring and a ball plunger for a firmer filament grip,
• “Unicorn” tri-metal copper nozzle with steel tip and titanium alloy heatbreak,
• 60 watt ceramic heater,
• Double fan for efficient, immediate partial cooling,
• Automatic calibration and levelling,
• 4.3 inch HD colour touchscreen,
• PEI spring steel plate,
• Creality OS for more flexibility.

Aesthetic and stable at the same time

Both the gantry and the base of the printer are made from a robust, mechanically strong ADC12 aluminium alloy and are manufactured using a die-casting process. The stable construction has few screws and connection points; its rounded corners and edges contribute to its stable and elegant appearance.

Speed beast with coordinated XZ movements

With its max. print speed of 600 mm/s and a max. acceleration of 20,000 mm/s², the Ender 3 V3 prints up to 12 times faster compared to a standard i3 3D printer, setting new standards for Bed Slinger.

Tip: In combination with Creality Hyper PLA filaments, the printer prints much faster and with higher quality.

Because the Ender 3 V3 's X and Z axes are connected, two high-torque motors work in unison to respond at lightning speed. This results in an impressive speed of 0 to 600 mm/s in just 0.03 seconds.

Thanks to precise linear guides and a fully automatic toothed belt, the Z axis can be positioned with the utmost precision. With a Z-axis accuracy of ≤ 15 µm, there is minimal Z-banding.

Extruder kit with quick-swap nozzle

The direct drive extruder of the Ender 3 V3 is reinforced by a bolster spring and a ball plunger for a firmer filament grip.

Upgrades:

► Lateral spring that strengthens the hold of the extruder gears,

► Ball plunger that holds the extruder lever in place,

► Powder metallurgy lever that maintains the extrusion force.

The so-called “Unicorn” tri-metal copper nozzle is equipped with a steel tip and a heatbreak made of titanium alloy. The long-lasting nozzle's integrated heatbreak blocks heat creep and can be easily replaced.

Danger! Allow the nozzle to cool before touching it with your hand.

60W heating element

The hotend is equipped with a powerful ceramic heater that can completely melt high-temperature filaments in no time. The heating element heats up from 0 to 300 °C in 75 seconds.

Efficient fans for instant cooling

There is a fan at the front and back of the print head, which hardens freshly printed layers quickly and evenly. This can prevent drooping, warping or stringing. The weight of the printhead fan is also dynamically balanced, reducing the likelihood of wobbling, ringing or ghosting.

Other features:

• Comes in pre-assembled modules, only 10 minutes are needed to assemble the 3D printer,
• Automatic calibration,
• Fully automatic XZ belt tension,
• 4.3 inch HD touchscreen with seamless touch response,
• Flexible, textured PEI plate with spring steel base,
• Klipper-based Creality OS with advanced features such as Linear Advance and Input Shaping.
